Machine feature

• Lead-edge feeding unit.
• 4 Shafts feed wheel.
• Linear guideway lateral moving device.
• Precious side squaring.
• Feeding stroke is adjustable.
• Skip feeding is available with counter.
• Trouble shooting with digital display.
• Volume air of feeding cam box is adjustable.

Features included

• Auto zero set.
• O.S and D.S side guide position motorized adjustment with digital display.
• Front stop gap and position adjusted manually.
• Backstop position motorized adjustment with digital cylinder.
• Side squaring fixed on THE OS guide and driven by air cylinder.
• Feed roll gap motorized adjustment with digital display.
• Quick-change feeding rubber roll.
• With hitch touch screen display on each unit and diagnostic display.
• Modem on line support.

Machine feature

• Top printing, vacuum box transfer with ceramic transfer wheel.
• Rubber roll ink system.
• Ceramic anilox roll.
• Out diameter of printing cylinder with printing plate: Φ405mm.
• PLC ink control system, ink circulate and quick washing system.

Features included

• Auto zero set.
• Anilox roll/printing cylinder gap motorized. Adjustment with digital display.
• Printing cylinder/impression roll gap motorized adjustment with digital display.
• PLC control printing register and printing horizontal move.
• Vacuum damper adjustment by pneumatic.
• Dust collector.
• Quick mounting printing plate device for saving order change time.

Machine feature

• Big pre-creaser, pre-creaser, creaser and slotter.
• Linear guideway lateral moving device with universal cross joints.

Features included

• Auto zero set.
• Single shaft double knife slotter structured.
• Creaser roll motorized adjustment with digital display.
• Slot shaft gap motorized adjustment with digital display.
• Center slot head movable, with long distance.
• Box height and slotter register motorized controlled by PLC.
• Use 7.5mm thickness slotter knife.

Machine feature

• Bottom die-cut for top printer.
• Out diameter of the die-cutting roll Φ360mm.
• C.U.E quick change anvil.

Features included

• Auto zero set.
• Anvil drum/ die cut drum gap motorized adjustment with digital display.
• Die-cutting cylinder gap motorized adjustment with digital display.
• Guide feed wheel gap motorized adjustment with digital display.
• Settable speed difference compensation to prolong the service of anvil cover.
• Grind the anvil cover with sand belt to prolong the service life of anvil cover.

Machine feature

• Top printer with down folding.
• Two belt transfer with high rigidity beam.
• Linear guideway lateral moving system.

Features included

• Auto zero set.
• Dual clean brushes to clean the corner knife scrap.
• Big gluing wheel, constant temperature glue system, liner guideway lateral moving system.
• Motorized control glue wheel position, reticulation gluing.
• Belt press wheel, motorized control gap adjustment according to board thickness.
• Folding guide wheel correct fish tail.
• Vacuum belt transfer to keep board right position.
• Lower folding belts with independent AC motor for belt speed regulating with touch screen display.
• Final squaring to correct fish tail.

Machine feature

• Top loading.
• Up to 25 bundles per minute.

Features included

• Servo motor driven.
• Back squiring and correction motorized control.
• Linear guideway lateral moving.
• Sheet bundle hold-down delivery belt.

Machine feature

• Microsoft window base computer control system for all the gap and box dimension adjustments with order memory capacity: 99,999 orders.

Features included

• Auto zero set for feeder, printers, slotters, die-cutter unit.
• Remote service support.
• Production and order management, available to connect with the customer internal ERP.
• Dimension/ calliper/ GAP automatic setting.
• Optimized order saving.
• Article date base for repeat order settings.
• Operator, maintenance and trouble-shooting support.
