Max. Mechanical Speed	250m/min
Production Line Length	About 95 meters
Flute Profiles	A, C, B, E flute
Total Power	3 Phase 380v 50hz 580kw

• Push the raw paper into place, light and flexible.
• The track is buried in the whole, the main frame is welded by 16 channels of steel, which is sturdy and durable.
• The upper cover steel plate is welded after installation on site.
• Hydraulic feeding paper trolley to load paper.

• The surface of the rolls are polished and plated with chrome.
• Electrical motion adjust of the dimension of per-heater, and the range of adjustment: 60-270 degree.
• Per-heater rolls professional manufactured, consistent with national safety standards for pressure vessels.
• Pre-heater roller and paper guide roll are plated.
• Electrical motion adjust of the dimension of per-heater, suit for different paper and speed.

• Hydraulic type, paper guiding method adopts wind suction to keep the corrugated shape stable at high speed.
• The fan absorbs the corrugated paper in the 180 degree range of the middle corrugated roller through the vacuum box to form a negative pressure zone to complete the corrugated rolling.
• The width of the suction groove of the lower corrugated roller does not exceed 2.5mm, which can reduce the stripe marks of single-sided corrugated cardboard.

• The transmission part adopts universal joint transmission to isolate the vibration source, which makes the transmission more stable.
• The gearbox adopts oil-immersion lubrication and closed gear transmission to reduce machine vibration.
• Adopt automatic cycle of glue supply, pneumatic gluing and reset, with buffer effect.
• The gluing area is adjusted electrically; gluing part operates independently when machine stops.
• The surface of the sizing roller is treated with special mesh engraving and chrome plating.
• The upper and lower corrugated rollers are made of high-quality alloy steel with hardness of HRC56-60 degrees.

• Symmetry structure could install two bundles real paper at the same time.
• Adopt hydraulic drive for lifting, clamping, release and moving.
• Adopt pneumatic strain to adjust the real paper.
• Tension control by multipoint brake system.

• Accurately sends single-sided corrugated cardboard to the next process via conveyor belt.
• Using suction tensioning device with 5.5KW high-pressure centrifugal frequency conversion fan.
• Equipped with two operating panels for adjustment in two places.
• Maintains a certain amount of board on the bridge to compensate for speed changes.

• Each roller surface is well whetted and chrome plated.
• Electrical motion adjust the dimension, range: 60-220°.
• Pre-heating roller made according to national container safety standards.

• 4 pneumatic cylinders to control the paper roller; gap is electrically adjusted.
• Synchronous setting with Double facer machine paperboard.
• Amount of glue controlled by PLC and adjusted according to speed.

• Overall high-strength wide channel steel structure.
• 600mm steel hot plate with multiple reinforcing ribs.
• Heating section adopts dense roller structure for firm gluing.

• Quickly remove waste cardboard to improve efficiency.
• Adopt Spiral-inlaid steel serrated blade.
• Schneider and Omron brand electrical appliances.

• Stores 999 sets of orders; realize automatic order change in 2-3 seconds.
• Taiwan Yonghong PLC and TECO servo control system.
• Thin tungsten steel alloy blade with service life over 8 million meters.

• High tensile strength wall plate with watching windows.
• Auto-cycling lubricating for transmitting precision.
• Adopts A.C. Servo drive for quick and exact action.

• Equipment for sorting, overlapping, conveying, and stacking cardboard.
• Three-section belt conveying for lower layer; four-segment for upper layer.
• Flexible adjustment of overlap based on production speed.
