The feeding unit is equipped with a pre-piling device to increase the production efficiency. It can be also equipped with a plate for paper pile directly pushing.
High strength feeder uses 4 lifting suckers and 5 forwarding suckers to ensure smooth running with no missing of sheet even at high speed.
Positioning device uses several sensors to sense corrugated board position; dual servo motors drive independently to align top paper accurately.
Electric control system with touch screen and PLC monitors working conditions and facilitates trouble shooting according to CE standards.
Gluing unit uses high precise coating and metering rollers for even gluing. Automatic glue level control system prevents overflow.
Machine body processed by CNC lathe ensures precision. Toothed belts guarantee smooth transferring with low noise.
Feeding unit adopts powerful servo motor control and high-pressure blower for consistent suction on various corrugated papers.
Automatic side lay adjustment via paper size input. Roller pressure adjusted synchronously by one hand wheel to protect flutes.
Why Choose Us?
Specializing in Flute Laminator products with exceptional quality and reliable performance.
Commitment to excellence and customer satisfaction as our primary work performance yardstick.
Products made with highest quality materials and precision engineering for superior performance.
Global recognition and export of multiple machine series to international markets.
Sufficient spot reserves and advanced resource tracking for timely equipment supply.
Core values focused on integrity, innovation, and win-win partnership development.
Frequently Asked Questions
What is the maximum sheet size the machine can handle?
The machine comes in different models; the LQCS-1450 supports up to 1400×1450mm, while the LQCS-16165 handles up to 1600×1650mm.
What types of paper weight are compatible?
The High Speed Automatic Flute Laminator is designed to work with sheet weights ranging from 157g/m² to 550g/m².
How does the machine ensure lamination precision?
The machine utilizes a combination of a motion control system, high-sensitivity servo motors, and sensor-based positioning to align the top paper and corrugated board accurately.
Is it easy to change orders for different paper sizes?
Yes, operators can easily change orders by inputting the paper size into the touch screen. All side lay adjustments are then finished automatically.
How does the gluing unit prevent glue overflow?
It features a unique gluing roller with a glue-stopping device and an automatic glue level control system that guarantees proper backflow without overflow.
Does the machine damage the corrugated flute during lamination?
No, the pressure of the rollers is adjusted synchronously by a single hand wheel to ensure even pressure, specifically designed to protect the flute from damage.
